Amphenol ICC (FCI) Minitek® 2.00mm, 16-circuit, 2-row, unshrouded male pin header, surface-mount solder termination, 2A rated, 30µinch GXT™ gold on mating contact, push-pull fastening, UL94 V-0 black thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | Minitek® 2.00mm |
| Gender | Male Pin |
| Mounting type | Surface Mount |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 200V (AC/DC) |
| Current rating | 2A (AC/DC) |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 16 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 57202-G52-08LF: Termination is solder-only — surface-mount pads on the PCB, no through-hole. The square male pins (0.079" pitch, 0.157" mating length) mate with a standard 2.00mm pitch receptacle. For a board stack, confirm the receptacle's mated stack height against your z-height budget.
No — the lifecycle status is Active. No LTB or successor has been issued by Amphenol ICC (FCI). You can commit this BOM line without an end-of-life watch.
This is an unshrouded male header. It mates with a standard 2.00mm pitch female receptacle from the same Minitek® 2.00mm series — look for a 16-position, dual-row socket housing with 2.00mm pitch and 0.079" row spacing. The mating pin length of 0.157" sets the stack height.
Rated 2A per contact at 200V AC/DC. The 2A ceiling is per the manufacturer spec; derate above ambient temperature per the product drawing.
Yes — RoHS compliant per the manufacturer listing. No separate certificate is held on file; the RoHS status is on the manufacturer's declaration.
