16-Pin Right-Angle Breakaway Header
In a vibration-prone environment, a secondary retention method — such as a wire-to-board housing with a positive lock — should be considered.
Tin-Plated Contacts at 3 A, 500 V
The mating contacts are tin-plated, rated for 3 A per contact at 500 V. Tin is a cost-effective finish for moderate-duty signal interconnects where the mating cycle count stays under 50–100 cycles. The post length is 0.122" (3.10 mm), suitable for a 1.6 mm thick PCB with a through-hole solder joint.
