JST B9PS-VH(LF)(SN) VH Header, 9 Pos, 3.96mm, 10A

MPNB9PS-VH(LF)(SN)
Active

JST VH series B9PS-VH(LF)(SN), 9-position single-row right-angle through-hole header, tin-plated brass contacts, 0.156" (3.96 mm) pitch, 10 A per circuit at 250 V, shrouded 1-wall with locking ramp, UL94 V-0 PA66 insulator, -25°C to 85°C, solder termination, bulk package.

$0.6800Ref. price · indicative, final on quote
B9PS-VH(LF)(SN) datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

B9PS-VH(LF)(SN) Technical Specifications
ParameterValue
SeriesVH
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typeLocking Ramp
Voltage rating250V
Current rating10A
Operating temperature-25°C~85°C
Contact materialBrass
Insulation colorNatural
Insulation height0.335\" (8.51mm)
Insulation materialPolyamide (PA66), Nylon 6/6
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageBulk
ShroudingShrouded - 1 Wall
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.156\" (3.96mm)
Positions9
Contact finish - postTin
Contact length - post0.142\" (3.60mm)
Contact finish - matingTin
Contact length - mating0.303\" (7.70mm)

Product details

Board-to-wire interconnect with a locking ramp

The 0.156" (3.96 mm) pitch sets the board footprint — a 9-position single-row pattern with 3.96 mm between centres.

How it compares to the straight sibling

The B9PS-VH(LF)(SN) is the right-angle version of the VH series 9-position header. The straight-through variant B9P-VH-B(LF)(SN) shares the same pitch, current rating, and tin plating, but its vertical orientation changes the board footprint and the harness routing. Both are active and RoHS-compliant.
