HILR-08VF-2-R — JST product photo
JST

JST HILR-08VF-2-R Receptacle Housing, 8 Pos, 3.30mm, Red

MPNHILR-08VF-2-R
Active

JST HIL series receptacle housing, 8 positions, 2 rows, 0.130" (3.30mm) pitch, crimp termination, free hanging, red PA66, latch holder, contacts not included.

$0.4794Ref. price · indicative, final on quote
HILR-08VF-2-R datasheet
StockIn Stock (15)
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

HILR-08VF-2-R Technical Specifications
ParameterValue
SeriesHIL
GenderMale Pin
Mounting typeFree Hanging (In-Line)
Connector typeReceptacle
Fastening typeLatch Holder
Operating temperature-25°C ~ 85°C
ColorRed
Insulation materialPolyamide (PA66), Nylon 6/6
NoteContacts Not Included
Pitch0.130\" (3.30mm)
PackageBulk
Row spacing0.130\" (3.30mm)
Rows2
Contact terminationCrimp
Positions8

Product details

Housing for the HIL Series — 8 Circuits, Red, Latch-Locked

The JST HILR-08VF-2-R is an 8-position, 2-row receptacle housing from the JST HIL series. It is a free-hanging (in-line) connector body designed for crimp-terminated male pin contacts — the contacts themselves are not included and must be ordered separately. The housing is molded in red polyamide (PA66) with a 0.130" (3.30mm) pitch between positions and an integrated latch holder for secure mating.

What It Mates With and What Contacts It Takes

This receptacle housing mates with the corresponding HIL series pin header (male pin header, same pitch and row count). The crimp terminals used are the male pin contacts from the HIL series — order those separately as they are not included with this housing.

Frequently asked questions

Where can I buy the HILR-08VF-2-R?

The HILR-08VF-2-R is sourced to order through independent distribution. Submit an RFQ for current availability and pricing — stock and lead time are confirmed at quote time.

Does the HILR-08VF-2-R come with contacts?

No — the listing explicitly notes that contacts are not included. You must order the matching HIL series male pin crimp terminals separately.

What is the mating connector for HILR-08VF-2-R?

It mates with the corresponding HIL series pin header (male pin header) at the same 0.130" (3.30mm) pitch and 8-position, 2-row layout.

Is HILR-08VF-2-R RoHS compliant?

RoHS compliance is standard for JST's current production parts. Confirm with the datasheet or your compliance team for the specific lot.
