JST SHR-02V-S-B Receptacle Housing, 2 Pos 1.00mm

MPNSHR-02V-S-B
Active

JST SH series receptacle housing, SHR-02V-S-B, 2 positions, 1.00mm pitch, single row, natural, free-hanging inline, crimp termination, female socket contacts not included.

$0.1000Ref. price · indicative, final on quote
SHR-02V-S-B datasheet
StockIn Stock (31)
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

SHR-02V-S-B Technical Specifications
ParameterValue
SeriesSH
GenderFemale Socket
Mounting typeFree Hanging (In-Line)
Connector typeReceptacle
Operating temperature-25°C~85°C
ColorNatural
NoteContacts Not Included
Pitch0.039\" (1.00mm)
PackageBulk
Rows1
Contact terminationCrimp
Positions2

Product details

The JST SHR-02V-S-B is a 2-position receptacle housing from the SH series, built for 1.00 mm pitch wire-to-board or wire-to-wire interconnects. It accepts female socket crimp terminals and mounts free-hanging inline — the standard approach for harness assemblies where the connector floats off the board. The natural PBT housing carries an operating range of -25°C to 85°C, which covers indoor electronics, consumer gear, and automotive cabin environments. Contacts are ordered separately.

Contacts Are Not Included — Plan the BOM Line

The housing ships without crimp terminals. The mating female socket contacts for the SH series must be ordered as a separate line item and crimped onto the wire before insertion.

Mates With the Matching SH Header

This receptacle housing mates with the JST SH series pin header. The 1.00 mm pitch and single-row layout are consistent across the SH family.

Frequently asked questions

Is SHR-02V-S-B a direct replacement for SHR-02V-S?

Yes, the two parts are functionally identical — same 2 positions, 1.00 mm pitch, natural colour, free-hanging mount, and crimp termination. The '-B' suffix is the only order code difference. They swap in the same harness position.
