JST XAP-14V-1 Receptacle Housing, 14 Pos, 2.50mm

MPNXAP-14V-1
Active

JST XA series receptacle housing, XAP-14V-1, 14 positions, 1 row, 2.50mm pitch, natural PA66, crimp termination, free-hanging, latch lock.

$0.3000Ref. price · indicative, final on quote
StockIn Stock (21)
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

XAP-14V-1 Technical Specifications
ParameterValue
SeriesXA
GenderFemale Socket
Mounting typeFree Hanging (In-Line)
Connector typeReceptacle
Fastening typeLatch Lock
Operating temperature-25°C~85°C
ColorNatural
NoteContacts Not Included
Pitch0.098\" (2.50mm)
PackageBulk
Rows1
Contact terminationCrimp
Positions14

Product details

Typical applications include internal power and signal harnesses in consumer electronics, small appliances, and automotive interior modules where a compact, polarized, and vibration-resistant connector is needed.

Pitch and Position Count — Matching the BOM Line

The 14-position count is the primary BOM match criterion — this housing fits only a 14-circuit header. The 2.50mm pitch is the same across the XA series, so the board footprint for the mating header is consistent whether you use the 12-position XAP-12V-1, this 14-position XAP-14V-1, or the 15-position XAP-15V-1.

Contacts Not Included — Plan Your Terminal Order

The housing ships without contacts.

Frequently asked questions

Does XAP-14V-1 come with contacts?

No. The housing is sold without contacts — the listing explicitly notes Contacts Not Included. You must order the matching female socket crimp terminals separately from the JST XA series.

What header mates with XAP-14V-1?

XAP-14V-1 mates with any JST XA series pin header of the same 14-circuit count and 2.50mm pitch. The latch-lock on the housing engages with the corresponding ramp on the header for a secure, polarized connection.
