JST XH series, XHP-9, 9-position receptacle housing, 1-row, 2.50mm pitch, crimp termination, free-hanging, natural PA6 nylon, contacts not included.
| Parameter | Value |
|---|---|
| Series | XH |
| Gender | Female Socket |
| Mounting type | Free Hanging (In-Line) |
| Connector type | Receptacle |
| Operating temperature | -25°C ~ 85°C |
| Color | Natural |
| Insulation material | Polyamide (PA6), Nylon 6 |
| Note | Contacts Not Included |
| Pitch | 0.098\" (2.50mm) |
| Package | Bulk |
| Rows | 1 |
| Contact termination | Crimp |
| Positions | 9 |
The JST XHP-9 is the 9-circuit receptacle housing from the XH series, a 2.50 mm pitch wire-to-board interconnect family.
The crimp termination means you can field-terminate wires with a standard JST hand tool, which makes this a repairable connector: if a terminal backs out or corrodes, you re-pin the housing on site instead of scrapping the whole harness.
The pitch is 0.098" (2.50 mm), standard for the JST XH series wire-to-board interconnect family.
The XHP-9 accepts female socket crimp terminals from the JST XH series. The housing ships empty — contacts must be ordered separately.
Yes, XHP-9 is ROHS3 compliant, suitable for RoHS-regulated markets without exemption documentation.
