Samtec Inc. HW-05-14-G-D-834-366
MPNHW-05-14-G-D-834-366
Active
HIGH TEMPERATURE FLEXIBLE BOARD
$2.7Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesFlex Stack, HW
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Flex Stack, HW |
| Mounting | Through Hole |
| Color | Black, Natural |
| Length - stack height | 0.834\" (21.184mm) |
| Pitch | 0.100\" (2.54mm) |
| Package | Bulk |
| Row spacing | 0.100\" (2.54mm) |
| Termination | Solder |
| Length - tail | 0.366\" (9.296mm) |
| Rows | 2 |
| Positions | 10 |
| Length - overall pin | 1.430\" (36.322mm) |
| Length - post (Mating) | 0.230\" (5.842mm) |
| Contact finish - post (Mating) | Gold |
| Contact finish thickness - post (Mating) | 10.0µin (0.25µm) |
