About the TE Connectivity AMP Connectors 1986 Header Plugs Sockets Series

IC Source Direct is a China connector distributor, supplier and independent procurement agent for TE Connectivity AMP Connectors 1986 Header Plugs Sockets Series components, matching housing, contact and mating cycles across the Shenzhen interconnect channel. The TE Connectivity AMP Connectors 1986 Header Plugs Sockets Series series groups 7 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common color of Green, contact material of Phosphor Bronze and contact mating finish of Tin. Variants differ by current - UL, features and insulation height, so you can match the exact current - UL your application requires using the selection guide below. All listed TE Connectivity AMP Connectors 1986 Header Plugs Sockets Series part numbers are active and orderable.

Select a variant by

Current - UL: 11 A · 16 A
Features: Retention Latches (Non-Wire Side) · Side Stacking
Insulation height: 0.587\" (14.91mm) · 0.756\" (19.20mm)
Operating temperature: -40°C ~ 105°C · -40°C ~ 110°C · -40°C~110°C
Pitch: 0.138\" (3.50mm) · 0.197\" (5.00mm) · 0.200\" (5.08mm)
Plug wire entry: 90° · 180° · 270°
Positions: 2 · 3 · 4 · 5 · 8
Positions per level: 2 · 3 · 4 · 5 · 8

Shared specifications

Color: Green
Contact material: Phosphor Bronze
Contact mating finish: Tin
Contact tail length: -
Current - IEC: -
Header orientation: -
Housing material: Polyamide (PA66), Nylon 6/6
IP rating: -
Material flammability rating: UL94 V-0
Mounting: Free Hanging (In-Line)
Number of levels: 1
Package: Bulk

Variant comparison

Parameter	1986300-4	1986370-5	1986370-8	1986371-2	1986371-3	1986371-4
Current - UL	16 A	11 A	11 A	11 A	11 A	11 A
Features	Retention Latches (Non-Wire Side)	Side Stacking	Side Stacking	Side Stacking	Side Stacking	Side Stacking
Insulation height	0.587\" (14.91mm)	0.756\" (19.20mm)	0.756\" (19.20mm)	0.756\" (19.20mm)	0.756\" (19.20mm)	0.756\" (19.20mm)
Operating temperature	-40°C ~ 105°C	-40°C ~ 110°C	-40°C~110°C	-40°C ~ 110°C	-40°C ~ 110°C	-40°C ~ 110°C
Pitch	0.197\" (5.00mm)	0.138\" (3.50mm)	0.138\" (3.50mm)	0.138\" (3.50mm)	0.138\" (3.50mm)	0.138\" (3.50mm)
Plug wire entry	180°	90°	90°	270°	270°	270°
Positions	4	5	8	2	3	4
Positions per level	4	5	8	2	3	4

Request a quote on any TE Connectivity AMP Connectors 1986 Header Plugs Sockets Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
