Würth Elektronik 614004185023 — USB / HDMI Cable Assemblies

Würth Elektronik 614004185023 USB-A Receptacle, 4-Pos

MPN614004185023
Active

Würth Elektronik WR-COM USB-A (USB TYPE-A) receptacle, order code 614004185023, 4 contacts, single port, USB 2.0, 1.5 A, 30VAC, gold-plated contacts, through-hole vertical, solder termination, board lock, unshielded.

$2.02Ref. price · indicative, final on quote
Würth Elektronik 614004185023 datasheet (PDF)
RoHSROHS3 Compliant
SeriesWR-COM
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — typically 7–15 days door-to-door
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

614004185023 key specifications
ParameterValue
SeriesWR-COM
MountingThrough Hole
Connector typeUSB-A (USB TYPE-A)
Voltage - rated30VAC
Current rating1.5A
Positions4
Mounting featureVertical
Operating temperature-55°C ~ 85°C
Insulation colorWhite
Shell (Shielding material)Brass
Material flammability ratingUL94 V-0
GenderReceptacle

All specifications

614004185023 additional specifications
ParameterValue
PackageTray
FeaturesBoard Lock
ShieldingUnshielded
TerminationSolder
Mating cycles1500
Contact finishGold
SpecificationsUSB 2.0
Number of ports1

Product details

USB-A vertical receptacle with board lock

The 614004185023 is a 4-contact USB-A receptacle in Würth Elektronik's WR-COM series, specified for USB 2.0 signal duty. Gold-plated contacts rated 1.5 A at 30VAC, through-hole vertical mounting with a board lock for reflow retention, and 1500 mating cycles.

Shielded vs unshielded in the same footprint

The unshielded 614004185023 shares the same vertical USB-A footprint, board lock, and gold-plated contacts with the shielded 614004134726 and 614004135023 — the shell material and plating are identical; the shielding layer is the only difference.

Frequently asked questions

What is the difference between 614004185023 and 614004134726?

614004185023 is unshielded; 614004134726 is shielded. Both are vertical USB-A receptacles with the same contact count, current rating, and board lock.
