10027011-106HLF — Amphenol product photo
Amphenol

10027011-106HLF 6-Pin Header, 2.54mm Pitch, SMT Right Angle

MPN10027011-106HLF
Active

Amphenol ICC (FCI) BERGSTIK® II, 10027011-106HLF, Board to Board, Header, Breakaway, 6 Positions, 0.100" (2.54mm) Pitch, Surface Mount, Right Angle, 3A, Gold 30.0µin Mating, Tin Post, UL94 V-0, Black, Active, RoHS

$1.0000Ref. price · indicative, final on quote
10027011-106HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

10027011-106HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeSurface Mount, Right Angle
Connector typeHeader, Breakaway
Fastening typePush-Pull
Current rating3A
Operating temperature-65°C~125°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.095\" (2.41mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions6
Contact finish - postTin
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

The 10027011-106HLF: The header is a breakaway design, meaning the 6-position strip can be snapped from a longer strip during assembly.

What 30.0 µin Gold Means for Reliability

For applications requiring frequent field reconnection, the same gold layer reduces insertion force variation over life compared to tin-plated contacts. The contact base metal is phosphor bronze, which offers good spring properties and fatigue resistance for the cantilever beam of the mating receptacle.

Comparing Gold Thickness: 30 µin vs 15 µin

The 30.0 µin version (10027011-106HLF) provides roughly double the mating-cycle endurance — a meaningful difference if the connector lives in a field-service panel that sees quarterly reconnects over a decade. The choice between them hinges on the required reconnection duty and environmental exposure, not on electrical performance.

Frequently asked questions

What is the closest functional equivalent to 10027011-106HLF?

The 68016-106HLF is a through-hole right-angle version with the same 6 positions, pitch, and gold plating. It is also active and from the same BERGSTIK® II series. The only difference is the termination method: surface mount vs through-hole. If your board layout requires SMT, stick with 10027011-106HLF; if through-hole is acceptable, 68016-106HLF is a drop-in alternative.
