Amphenol ICC (FCI) BERGSTIK® header, breakaway, order code 77313-185-42LF, 42 positions, dual row, 0.100" (2.54 mm) pitch, 3 A per contact, gold or GXT™ mating finish, through-hole, solder termination.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Gender | Male Pin |
| Mounting type | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 42 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.114\" (2.90mm) |
| Overall contact length | 0.626\" (15.90mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.413\" (10.50mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 77313-185-42LF is the 42-position member of Amphenol ICC's BERGSTIK® breakaway header line, configured as a board-to-board or cable unshrouded male pin header with push-pull fastening.
Order against BOM quantity; availability confirmed at RFQ.
No official successor or pin-compatible cross-reference is listed.
