SE1014023111111 — Amphenol product photo
Amphenol

SE1014023111111 Slim Cool Edge 0.65mm

MPNSE1014023111111
Active

Slim Cool Edge 0.65mm series, female dual-edge connector, 140 positions, 0.026" (0.65mm) pitch, 2 rows, surface mount, gold 30.0µin contacts, black thermoplastic housing, tape and reel.

$9.5900Ref. price · indicative, final on quote
SE1014023111111 datasheet
StockIn Stock (20)
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

SE1014023111111 Technical Specifications
ParameterValue
SeriesSlim Cool Edge 0.65mm
Card typeNon Specified - Dual Edge
GenderCantilever
Mounting typeSurface Mount
Operating temperature-55°C ~ 105°C
ColorBlack
Contact materialCopper Alloy
Material - insulationThermoplastic
Pitch0.026\" (0.65mm)
PackageTape & Reel (TR) Cut Tape (CT)
FeaturesBoard Guide, Solder Retention
Read outDual
TerminationSolder
Card thickness0.063\" (1.60mm)
Contact finishGold
Rows2
Positions140
Contact finish thickness30.0µin (0.76µm)

Product details

0.65mm Pitch, 140-Position Dual-Edge Connector for High-Density Card Interfaces

The SE1014023111111 is a 140-position, dual-readout female edge connector from the Slim Cool Edge 0.65mm series. It mates with a 0.063" (1.60mm) thick daughtercard, using cantilever contacts on a 0.026" (0.65mm) pitch across two rows.

140 Positions at 0.65mm Pitch — What the Density Means for Board Layout

Each cantilever contact wipes the card pad on insertion — the dual readout means the connector contacts both sides of the PCB, doubling signal density per linear inch of board edge. If the BOM calls for more signals at the same pitch, the SE1020023111111 carries 200 positions in the same 0.65mm pitch and 30.0µin gold finish — a direct position-count alternative for wider buses.

Surface-Mount Termination and Tape & Reel Packaging

Termination is solder-only — surface mount, no through-hole variant in this series.

Frequently asked questions

What is the pitch and number of contacts on SE1014023111111?

The SE1014023111111 has 140 positions on a 0.026" (0.65mm) pitch, arranged in two rows for dual-readout on a 0.063" (1.60mm) thick daughtercard.

Is SE1014023111111 RoHS compliant and lead-free?

Yes, the SE1014023111111 is ROHS3 compliant.

Does SE1014023111111 have any board retainers or solder retention features?

Yes, the housing includes board guide and solder retention features to aid alignment during reflow and resist shear from card insertion.
