JAE Electronics Board-to-Board Connectors — 58 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

MPN	Price (est.)	Actions	Positions	Series	Pitch	Connector Size	Features	Mounting	Package	Status
AC01P080WA1R500	RFQ	Details	80	AC01	0.020" (0.50 mm)	Center Strip Contacts, Plug	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
AC01P100WA1R500	RFQ	Details	100	AC01	0.020" (0.50 mm)	Center Strip Contacts, Plug	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
AC01S050WA1R3000	RFQ	Details	50	AC01	0.020" (0.50 mm)	Outer Shroud Contacts, Receptacle	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
AC01S080WA1R3000	RFQ	Details	80	AC01	0.020" (0.50 mm)	Outer Shroud Contacts, Receptacle	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
AC01S100WA1R500	RFQ	Details	100	AC01	0.020" (0.50 mm)	Outer Shroud Contacts, Receptacle	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
KX15-20K3DE	RFQ	Details	20	KX15	0.031" (0.80 mm)	Center Strip Contacts, Plug	-	Surface Mount	Tray	Active
MA01R040HAYBR600	RFQ	Details	40	MA01	0.025" (0.64 mm)	Outer Shroud Contacts, Receptacle	-	Right Angle, Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
TX24-100R-LT-H1E	RFQ	Details	100	TX24	0.050" (1.27 mm)	Outer Shroud Contacts, Receptacle	-	Right Angle, Through Hole	Tray	Active
TX24-30R-6ST-H1E	RFQ	Details	30	TX24	0.050" (1.27 mm)	Outer Shroud Contacts, Receptacle	-	Through Hole	Tray	Active
TX24-30R-LT-H1E	RFQ	Details	30	TX24	0.050" (1.27 mm)	Outer Shroud Contacts, Receptacle	-	Right Angle, Through Hole	Tray	Active
TX24-40R-6ST-N1E	RFQ	Details	40	TX24	0.050" (1.27 mm)	Outer Shroud Contacts, Receptacle	-	Through Hole	Tray	Active
TX24-40R-LT-H1E	RFQ	Details	40	TX24	0.050" (1.27 mm)	Outer Shroud Contacts, Receptacle	-	Right Angle, Through Hole	Tray	Active
TX24-50R-LT-H1E	RFQ	Details	50	TX24	0.050" (1.27 mm)	Outer Shroud Contacts, Receptacle	-	Right Angle, Through Hole	Tray	Active
TX24-50R-LT-N1E	RFQ	Details	50	TX24	0.050" (1.27 mm)	Outer Shroud Contacts, Receptacle	-	Right Angle, Through Hole	Tray	Active
TX24-60R-6ST-H1E	RFQ	Details	60	TX24	0.050" (1.27 mm)	Outer Shroud Contacts, Receptacle	-	Through Hole	Tray	Active
TX24A-80R-LT-H1E	RFQ	Details	80	TX24 A	0.050" (1.27 mm)	Outer Shroud Contacts, Receptacle	-	Right Angle, Through Hole	Tray	Active
TX25-100P-LT-H1E	RFQ	Details	100	TX25	0.050" (1.27 mm)	Center Strip Contacts, Plug	-	Right Angle, Through Hole	Tray	Active
TX25-30P-6ST-H1E	RFQ	Details	30	TX25	0.050" (1.27 mm)	Center Strip Contacts, Plug	-	Through Hole	Tray	Active
TX25-30P-8ST-H1E	RFQ	Details	30	TX25	0.050" (1.27 mm)	Center Strip Contacts, Plug	-	Through Hole	Tray	Active
TX25-30P-LT-H1E	RFQ	Details	30	TX25	0.050" (1.27 mm)	Center Strip Contacts, Plug	-	Right Angle, Through Hole	Tray	Active
WP10-S002VA10-R15000	RFQ	Details	6 (2 + 4 Power)	WP10	0.016" (0.40 mm)	Center Strip Contacts, Receptacle	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
WP10-S004VA10-R15000	RFQ	Details	8 (4 + 4 Power)	WP10	0.016" (0.40 mm)	Center Strip Contacts, Receptacle	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
WP21-P010VA1-R8000	RFQ	Details	10	WP21	0.014" (0.35 mm)	Outer Shroud Contacts, Plug	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Not For New Designs
WP21-S010VA1-R8000	RFQ	Details	10	WP21	0.014" (0.35 mm)	Center Strip Contacts, Receptacle	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Not For New Designs
WP21-S020VA1-R8000	RFQ	Details	20	WP21	0.014" (0.35 mm)	Center Strip Contacts, Receptacle	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Not For New Designs
WP21-S040VA1-R8000	RFQ	Details	40	WP21	0.014" (0.35 mm)	Center Strip Contacts, Receptacle	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Obsolete
WP25D-P028VA1-R8000	RFQ	Details	28	WP25D	0.014" (0.35 mm)	Outer Shroud Contacts, Plug	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Not For New Designs
WP25D-S010VA1-R8000	RFQ	Details	10	WP25D	0.014" (0.35 mm)	Center Strip Contacts, Receptacle	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Not For New Designs
WP26-P024VA1-R15000	RFQ	Details	24	WP26	0.014" (0.35 mm)	Outer Shroud Contacts, Plug	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
WP26-S040VA1-R15000	RFQ	Details	40	WP26	0.014" (0.35 mm)	Center Strip Contacts, Receptacle	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
WP26DK-P040VA3-R15000	RFQ	Details	40	WP26DK	0.014" (0.35 mm)	Outer Shroud Contacts, Plug	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
WP27D-P010VA3-R15000	RFQ	Details	10	WP27D	0.014" (0.35 mm)	Outer Shroud Contacts, Plug	-	Surface Mount	Tape & Reel (TR) Cut Tape (CT)	Active
