JAE Electronics — USB, Type-C & HDMI Connectors

JAE Electronics USB, Type-C & HDMI Connectors — 20 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

title
D273-50155 · DC04S019JA1R600 · DC04S019JA2R600 · DC04S019JAAR200
Base Product Number
D273-501 · DC04S019 · DC1RS19J · DC2R019J
Mounting Type
Surface Mount, Right Angle; Through Hole · Panel Mount; Surface Mount, Right Angle; Through Hole · Surface Mount, Right Angle · Board Edge, Cutout; Surface Mount; Through Hole, Right Angle
Current Rating (Amps)
0.5A · 0.5A per Contact · 0.3A per Contact · 0.25A, 1.25A
Number of Contacts
19 · 20 · 24 · 24 (22+2 Dummy)
Specifications
HDMI 2.1 · Display Port 1.1a · USB 4.0 · USB 3.2 Gen 2 (USB 3.1 Gen 2, Superspeed + (USB 3.1))
Mounting Feature
Horizontal · Flange, Horizontal · Horizontal, Reverse Mount · Horizontal, Mid Mount
Connector Type
HDMI · HDMI - Mini · HDMI - Micro · DisplayPort
