Keystone Electronics — PCB Pin Sockets

Keystone Electronics PCB Pin Sockets — 20 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

title: 1411-1 · 1411-2 · 1413 · 1414
Length - Overall: 0.140" (3.56mm) · 0.170" (4.32mm) · 0.161" (4.09mm) · 0.236" (6.00mm)
Mounting Hole Diameter: 0.042" (1.07mm) · 0.057" (1.45mm) · 0.089" (2.26mm) · 0.055" (1.40mm)
Flange Diameter: 0.055" (1.40mm) · 0.072" (1.83mm) · 0.126" (3.20mm) · 0.086" (2.18mm)
Socket Depth: 0.142" (3.61mm) · 0.236" (5.99mm) · 0.130" (3.30mm) · 0.170" (4.32mm)
Accepts Pin Diameter: 0.015" ~ 0.021" (0.38mm ~ 0.53mm) · 0.015" ~ 0.025" (0.38mm ~ 0.64mm) · 0.032" ~ 0.046" (0.81mm ~ 1.17mm) · 0.022" ~ 0.034" (0.56mm ~ 0.86mm)
Termination: Solder · Press-Fit · Press-Fit, Knurled · Swage
Contact Finish: Gold · Tin-Lead
