TE 1-103956-5 AMPMODU MTE Receptacle, 5 Pos, 0.100" Pitch

MPN1-103956-5
Active

TE Connectivity AMPMODU MTE receptacle, 5 positions, 0.100" (2.54mm) pitch, 1 row, IDC termination, tin-plated female socket, free-hanging (in-line), latch lock, black housing, 22-26 AWG.

$1.8000Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesAMPMODU MTE
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1-103956-5 specifications
ParameterValue
SeriesAMPMODU MTE
Wire typeDiscrete
TypeFemale Socket
MountingFree Hanging (In-Line)
Connector typeReceptacle
Fastening typeLatch Lock
Wire gauge22-26 AWG
Cable terminationIDC
ColorBlack
Pitch0.100\" (2.54mm)
PackageBulk
Contact finishTin
Rows1
Positions5
Contact finish thickness100.0µin (2.54µm)

Product details

Typical use is in internal harnesses for industrial controls, telecom gear, and test equipment where you need a reliable, field-terminable connection without crimping.

This is an IDC (insulation displacement) receptacle — you don't strip or crimp the wire. The free-hanging mount means it sits in-line on the harness, not on a board. The latch lock then clicks onto the mating header pins. For field installation, you'll need an IDC hand tool or a bench press that matches the AMPMODU MTE slot geometry — the wire gauge range is narrow enough that the tool's anvil should be set for the specific wire diameter.

Contact Finish and Duty

Tin is a good choice for moderate mating-cycle applications (maybe a few dozen mates over the life of the equipment) in a dry, indoor environment. It won't handle the corrosion resistance of gold in a humid or chemically aggressive setting, but for a harness inside a cabinet that gets assembled once and serviced occasionally, this plating holds up fine. The thickness here is well above the typical tin flash, so it should resist fretting corrosion through the expected service life.

Sourcing

If you're filling a BOM line for a 5-position IDC receptacle, this is the TE part number to specify.

Frequently asked questions

Is 1-103956-5 RoHS compliant?

Yes, the 1-103956-5 is RoHS Compliant, so it meets the restricted-substance requirements for most commercial and industrial applications.
