The TE Connectivity 1-1969540-6 is a 16-circuit, 2-row receptacle housing in the Economy Power 2.5 series. It uses a 0.098" (2.50mm) pitch, matching the standard footprint for this wire-to-board connector family. The housing is white polyamide (nylon), rated for operation from -55°C to 105°C, and secures the mating header with a latch lock — a positive-retention feature that resists vibration in harness assemblies. This is a free-hanging (in-line) receptacle; it accepts crimp terminals that are ordered separately.
Mating Header and Contact Compatibility
This housing mates with the corresponding Economy Power 2.5 pin header of the same pitch and circuit count — a 16-position, 2-row header. The latch lock on the housing engages the header's locking ramp for a secure connection. The female socket contacts (crimp style) are not included; they must be ordered as a separate line item. The housing accepts terminals sized for 20-24 AWG wire, though the specific terminal part number depends on wire gauge and plating preference.
