TE Connectivity AMP Connectors header, order code 1-1971819-5, 5 positions, single row, 0.098" (2.50mm) pitch, Board to Cable/Wire style, tin-plated mating contacts, through-hole solder termination, shrouded 4-wall with locking ramp.
1-1971819-5 TE Connectivity AMP Connectors Header
MPN1-1971819-5
Active
TE Connectivity AMP Connectors header, order code 1-1971819-5, 5 positions, single row, 0.098" (2.50mm) pitch, Board to Cable/Wire style, tin-plated mating contacts, through-hole solder termination, shrouded 4-wall with locking ramp.
$0.5360Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Type | Tab |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Operating temperature | -40°C~120°C |
| Contact material | Copper Alloy |
| Insulation color | Natural |
| Insulation height | 0.516\" (13.11mm) |
| Insulation material | Polyamide (PA), Nylon |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tube |
All specifications
| Parameter | Value |
|---|---|
| Features | Board Guide, Glow Wire Compliant |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Rectangular |
| Rows | 1 |
| Pitch | 0.098\" (2.50mm) |
| Positions | 5 |
| Contact finish - post | Tin |
| Contact length - post | 0.114\" (2.90mm) |
| Contact finish - mating | Tin |
Product details
Frequently asked questions
What compliance documentation does TE Connectivity provide for 1-1971819-5?
RoHS/REACH documentation is available from TE Connectivity upon request.
