TE Connectivity AMP Connectors plug, female sockets, order code 1-1986692-3, 13 positions, single level, 0.138" (3.50mm) pitch, 9 A, 300 V, tin-plated contacts, push-in spring termination, free hanging, bulk.
| Parameter | Value |
|---|---|
| Type | Plug, Female Sockets |
| Mounting | Free Hanging (In-Line) |
| Voltage - UL | 300 V |
| Current - UL | 9 A |
| Plug wire entry | 180° |
| Wire gauge or range - AWG | 14-30 AWG |
| Wire gauge or range - mm2 | 0.05-2mm² |
| Operating temperature | -40°C~110°C |
| Color | Green |
| Contact material | Copper Alloy |
| Housing material | Polyamide (PA), Nylon |
| Insulation height | 0.459\" (11.66mm) |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Pitch | 0.138\" (3.50mm) |
| Package | Bulk |
| Features | Side Stacking |
| Number of levels | 1 |
| Termination style | Screwless - Leg Spring, Push-In Spring |
| Positions | 13 |
| Positions per level | 13 |
| Contact mating finish | Tin |
The 1-1986692-3 is the 13-circuit member of TE Connectivity's plug line for wire-to-board applications, using push-in spring termination for 14-30 AWG solid or stranded wire. Rated 9 A at 300 V with tin-plated mating contacts, the plug accepts wire from 0.05-2 mm² and carries a UL94 V-0 polyamide housing.
