TE Connectivity AMP Connectors plug, order code 1-1986726-5, 15 positions, single level, 3.81 mm pitch, 9 A, 300 V, tin-plated copper alloy contacts, free hanging (in-line), push-in spring termination.
| Parameter | Value |
|---|---|
| Type | Plug, Female Sockets |
| Mounting | Free Hanging (In-Line) |
| Voltage - UL | 300 V |
| Current - UL | 9 A |
| Plug wire entry | 180° |
| Wire gauge or range - AWG | 14-30 AWG |
| Wire gauge or range - mm2 | 0.05-2mm² |
| Operating temperature | -40°C~110°C |
| Color | Green |
| Contact material | Copper Alloy |
| Housing material | Polyamide (PA), Nylon |
| Insulation height | 0.459\" (11.66mm) |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Pitch | 0.150\" (3.81mm) |
| Package | Bulk |
| Features | Mating Flange |
| Number of levels | 1 |
| Termination style | Screwless - Leg Spring, Push-In Spring |
| Positions | 15 |
| Positions per level | 15 |
| Contact mating finish | Tin |
The 1-1986726-5 is a 15-position plug from TE Connectivity AMP Connectors, using female socket contacts with a tin mating finish and a free-hanging in-line mount.
No pin-compatible replacement is documented from the original manufacturer.
Pricing and stock are confirmed per RFQ. The part is available through independent surplus channels; quantities are lot-specific.
No pin-compatible alternative is documented from TE Connectivity AMP Connectors. A board spin may be required for a functional replacement.
