RAST 2.5 Tab Header – 11 Circuits, Locking Ramp
The 1-2367449-1: This is a 11-position, 2-row shrouded header from the RAST 2.5 family, designed for board-to-wire applications. The 2.50mm pitch and 3.75mm row spacing set the PCB footprint and mating interface with standard RAST 2.5 receptacles.
Glow Wire Compliance and Flame Rating
The header carries Glow Wire Compliant marking and UL94 V-0 flammability rating on the PA66 housing. This combination is required for IEC/EN 60335-1 household appliance safety — the housing resists ignition and self-extinguishes under glow-wire test conditions.
