The 1-2842150-0: Gold plating on the mating face (3.94 µinch over copper alloy) provides a corrosion-resistant, low-resistance interface rated for repeated mating cycles — a solid choice for field-serviceable assemblies where the connector sees periodic disconnect.
1-2842150-0 TE Connectivity AMPMODU Header, 20 Pos
MPN1-2842150-0
Active
TE Connectivity AMPMODU header, breakaway, 20 positions, 2.00 mm pitch, dual-row, right-angle through-hole, gold mating finish, UL94 V-0, active production.
$2.4300Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesAMPMODU
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Voltage rating | 125VAC/DC |
| Current rating | 2A |
| Operating temperature | -40°C~125°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.059\" (1.50mm) |
| Insulation material | Thermoplastic |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Tube |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 20 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.110\" (2.79mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 3.94µin (0.100µm) |
Product details
Frequently asked questions
What is the pin pitch and mounting type of 1-2842150-0?
The mating pitch is 2.00 mm (0.079") with a row spacing of 2.00 mm. The header mounts through-hole, right-angle, and is unshrouded.
