TE Connectivity AMP Connectors 1-2842284-0 — Pin Headers

1-2842284-0 TE Connectivity AMPMODU 2mm Header, 10 Pos, Gold

MPN1-2842284-0
Active

TE Connectivity AMPMODU 2 mm, 10-position, dual-row, shrouded header, male pin, through hole, gold mating finish, 2 A, 125 VAC/DC, UL94 V-0, tube pack.

$2.4100Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 1-2842284-0 datasheet (PDF)
RoHSROHS3 Compliant
SeriesAMPMODU
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1-2842284-0 key specifications
ParameterValue
SeriesAMPMODU
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeDetent Lock
Voltage rating125VAC/DC
Current rating2A
Operating temperature-40°C~125°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.238\" (6.05mm)
Insulation materialThermoplastic

All specifications

1-2842284-0 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageTube
ShroudingShrouded - 2 Wall
TerminationSolder
ApplicationsGeneral Purpose, Industrial
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions10
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact length - post0.110\" (2.79mm)
Contact finish - matingGold
Contact length - mating0.145\" (3.70mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

2.00 mm Pitch, 10-Position Dual-Row Shrouded Header

The 1-2842284-0: The tin-plated solder posts (78.7 µinch) are compatible with standard wave-solder profiles. This makes the header suitable for industrial cabinets, automotive modules, and outdoor telecom equipment where the enclosure requires flame-rated components.

Through-Hole Termination and Mechanical Fit

All 10 positions are loaded — no unpopulated pins to track. The black insulation color aids visual inspection during harness assembly.

Lifecycle status is Active, with ROHS3 compliance.

Frequently asked questions

Is the 1-2842284-0 shrouded?

Yes, it is a shrouded header with a 2-wall design.

Where can I buy 1-2842284-0 available via RFQ confirmation?

Sourced to order against your BOM quantity through independent distribution. Availability and current pricing confirmed at quote time.
