TE Connectivity AMP Connectors 1-338068-0 — Female Socket Headers

1-338068-0 TE Connectivity Micro-MaTch 10-Pin Receptacle

MPN1-338068-0
Active

TE Connectivity AMP Connectors Micro-MaTch, 1-338068-0, Receptacle, 10 Positions, 0.100" (2.54mm) Pitch, Through Hole, Tin, Friction Lock, UL94 V-0

$1.2800Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesMicro-MaTch
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1-338068-0 key specifications
ParameterValue
SeriesMicro-MaTch
TypeForked
MountingThrough Hole
Connector typeReceptacle
Fastening typeFriction Lock
Voltage rating100VDC
Operating temperature-40°C ~ 105°C
Contact materialPhosphor Bronze
Insulation colorRed
Insulation height0.157\" (4.00mm)
Insulation materialPolybutylene Terephthalate (PBT), Polyester, Glass Filled
Material flammability ratingUL94 V-0

All specifications

1-338068-0 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageBulk
TerminationKinked Pin, Solder
ApplicationsAutomotive, General Purpose
Rows2
Pitch0.100\" (2.54mm)
Positions10
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.122\" (3.10mm)
Contact finish - matingTin

Product details

10-position dual-row Micro-MaTch receptacle

The 1-338068-0 is a 10-position, dual-row receptacle from TE's Micro-MaTch series, designed for board-to-board or cable applications. The friction lock provides positive retention against vibration without a secondary latch, which is a practical advantage in automotive and general-purpose environments. The red insulation aids visual identification on the board.

Specs that drive the board fit

The through-hole termination uses kinked pins for solder retention during wave soldering. The contact length after the board is 0.122" (3.10mm), which sets the minimum PCB thickness for a reliable solder fillet. Tin contact finish suits low-voltage signal applications.

Sourcing and compliance

Sourced to order against the BOM quantity. Current pricing and lead time are confirmed at quote time — submit an RFQ for the exact quantity and delivery window.

Frequently asked questions

What is the mating connector for 1-338068-0?

The friction lock on the receptacle engages with a corresponding latch on the header. Confirm the header's position count and row spacing match the 10-position, dual-row layout.

Is 1-338068-0 RoHS compliant?

Yes, it is ROHS3 compliant.
