TE Connectivity AMP Connectors, High Performance Interconnect (HPI) series, Board to Cable/Wire Header, 11 positions, 2.00 mm pitch, shrouded 4-wall, press-fit and solder termination, tin contacts, UL94 V-0, -25°C to 85°C, 3 A, 250 V.
| Parameter | Value |
|---|---|
| Series | High Performance Interconnect (HPI) |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Voltage rating | 250V |
| Current rating | 3A |
| Operating temperature | -25°C ~ 85°C |
| Contact material | Brass |
| Insulation color | Natural |
| Insulation height | 0.238\" (6.05mm) |
| Insulation material | Polyamide (PA66), Nylon 6/6 |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Bulk |
| Shrouding | Shrouded - 4 Wall |
| Termination | Press-Fit, Solder |
| Applications | Automotive, General Purpose, Industrial, Medical |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 11 |
| Contact finish - post | Tin |
| Contact length - post | 0.134\" (3.40mm) |
| Overall contact length | 0.335\" (8.51mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.132\" (3.35mm) |
| Contact finish thickness - post | 80.0µin (2.03µm) |
| Contact finish thickness - mating | 80.0µin (2.03µm) |
The 1-440054-1: This is a single-row, 11-position header from TE's High Performance Interconnect (HPI) series, designed for board-to-cable/wire applications where a shrouded 4-wall housing protects the male pins during mating and handling.
Yes, the 1-440054-1 is ROHS3 compliant per the manufacturer's status.
As a shrouded 4-wall header with 2.00 mm pitch, it mates with a matching 11-position receptacle housing from the same HPI series. Confirm the specific receptacle part number against your harness design.
The header has 11 positions all loaded in a single row. The pinout is a straight 1x11 layout; the mating contact sequence depends on the receptacle terminal loading.
