What This 6-Position Universal MATE-N-LOK Plug Housing Does
It uses a 3-row layout with a 0.250" (6.35mm) row spacing, which gives you enough room between circuits to handle moderate power levels without creepage issues at the board or splice joint.
You'll need to order the appropriate Universal MATE-N-LOK crimp terminals separately. The housing accepts both male pin and female socket contacts, so you can build a plug assembly that mates with the corresponding receptacle housing (typically the 1-480704 series or its receptacle counterpart).
Row Spacing and Polarization — What Fits Where
The 3-row, 6-position arrangement uses a 0.250" (6.35mm) row spacing — that's the center-to-center distance between rows. The housing is keyed (polarized) to prevent mismating with the wrong receptacle. The latch lock engages on the receptacle side; you'll hear it click when fully seated. For a direct mate, look for the matching 6-position Universal MATE-N-LOK receptacle housing with the same 3-row, 0.250" row spacing layout.
