TE Connectivity AMPMODU header, order code 1-5084108-2, 50 positions, dual row, 2.00 mm pitch, gold or gold-palladium mating contacts, surface-mount right-angle, solder termination, board lock.
| Parameter | Value |
|---|---|
| Series | AMPMODU |
| Type | Male Pin |
| Mounting | Board Edge, Cutout; Surface Mount, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.079\" (2.00mm) |
| Insulation material | Polyphenylene Sulfide (PPS) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Parameter | Value |
|---|---|
| Features | Board Lock |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 50 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold or Gold-Palladium |
| Contact length - mating | 0.152\" (3.86mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 1-5084108-2 is the 50-position member of TE's AMPMODU header line, dual-row, 2.00 mm pitch, unshrouded with push-pull fastening. A board lock secures the part during reflow.
The unshrouded design leaves the pin tips exposed for board-edge or cutout mounting.
The listed style is Board to Board or Cable.
