TE Connectivity AMPMODU Mod II receptacle, order code 1-535676-1, 12 positions, single row, 0.100" (2.54 mm) pitch, gold-plated mating contacts, through-hole right-angle, solder termination.
1-535676-1 TE AMPMODU Mod II Receptacle, 12 Pos
MPN1-535676-1
Active
TE Connectivity AMPMODU Mod II receptacle, order code 1-535676-1, 12 positions, single row, 0.100" (2.54 mm) pitch, gold-plated mating contacts, through-hole right-angle, solder termination.
$1.8400Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Female Socket |
| Mounting | Through Hole, Right Angle |
| Connector type | Receptacle |
| Fastening type | Push-Pull |
| Operating temperature | -55°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.137\" (3.47mm) |
| Insulation material | Polyester, Glass Filled |
| Style | Board to Board |
| Package | Tube |
All specifications
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 12 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.115\" (2.92mm) |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 50.0µin (1.27µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What compliance documentation is available for the 1-535676-1?
The part is listed under TE Connectivity AMP Connectors; RoHS and REACH compliance documentation is provided by the manufacturer for the 1-535676-1.
