TE Connectivity AMP Connectors MTA-156 series, 1-640383-3, Board to Cable/Wire, Header, Male Pin, 13 Positions, 1 Row, 0.156" (3.96mm) Pitch, Through Hole, Solder, Tin, Unshrouded, UL94 V-0, -55°C ~ 105°C, 600VAC
| Parameter | Value |
|---|---|
| Series | MTA-156 |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Voltage rating | 600VAC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -55°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Natural |
| Insulation height | 0.125\" (3.18mm) |
| Insulation material | Thermoplastic, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Applications | General Purpose, Industrial |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.156\" (3.96mm) |
| Positions | 13 |
| Contact finish - post | Tin |
| Contact length - post | 0.125\" (3.18mm) |
| Overall contact length | 0.650\" (16.51mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.400\" (10.16mm) |
The 1-640383-3 is a 13-position, single-row, unshrouded header from TE's MTA-156 series, designed to mate with MTA-156 IDC receptacles for board-to-cable/wire connections.
Termination is through-hole solder with a 0.125" (3.18mm) post length, and the mating contact length is 0.400" (10.16mm).
1-640383-3 is an active TE Connectivity part. We source it per RFQ — submit a request with your target quantity and we will confirm availability and current pricing at quote time.
Yes, this header is designed for the MTA-156 series. It mates with the matching MTA-156 IDC receptacle housings and crimp terminals. Confirm the receptacle part number against your assembly before ordering.
