TE Connectivity AMP Connectors Mini-Universal MATE-N-LOK header, 1-770971-0, 10 circuits, 2 rows, 4.14 mm pitch, right-angle through-hole, shrouded 4-wall, tin contacts 150.0µin, locking ramp, board lock, UL94 V-0, -20°C~85°C, 600VAC, RoHS, Active.
| Parameter | Value |
|---|---|
| Series | Mini-Universal MATE-N-LOK |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 600VAC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -20°C~85°C |
| Contact material | Brass |
| Insulation color | White |
| Insulation height | 0.386\" (9.80mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Features | Board Lock |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Circular |
| Rows | 2 |
| Pitch | 0.163\" (4.14mm) |
| Positions | 10 |
| Row spacing - mating | 0.163\" (4.14mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.145\" (3.68mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
The 1-770971-0: A locking ramp fastens the mating receptacle, providing vibration resistance — useful in industrial cabinets or automotive interiors where the connector sees movement.
Voltage rating is 600VAC, which covers most low-voltage power distribution and signal applications. The insulation material is polyamide (nylon), white in color, with an insulation height of 0.386" (9.80 mm).
