TE Connectivity Mini-Universal MATE-N-LOK header, 1-794066-1, 12 circuits, 4.14 mm pitch, shrouded with locking ramp, through-hole solder termination, gold-over-nickel mating contacts, board lock, UL94 V-0.
1-794066-1 TE Connectivity Header 12 Pos 4.14mm Pitch
MPN1-794066-1
Active
TE Connectivity Mini-Universal MATE-N-LOK header, 1-794066-1, 12 circuits, 4.14 mm pitch, shrouded with locking ramp, through-hole solder termination, gold-over-nickel mating contacts, board lock, UL94 V-0.
$6.4300Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesMini-Universal MATE-N-LOK
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Mini-Universal MATE-N-LOK |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 600VAC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -20°C~105°C |
| Contact material | Brass |
| Insulation color | White |
| Insulation height | 0.531\" (13.50mm) |
| Insulation material | Polyamide (PA), Nylon |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Features | Board Lock |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Circular |
| Rows | 2 |
| Pitch | 0.163\" (4.14mm) |
| Positions | 12 |
| Row spacing - mating | 0.163\" (4.14mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.175\" (4.45mm) |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
Where can I buy 1-794066-1 and how do I get a price?
1-794066-1 is an active part sourced through independent distribution.
Is 1-794066-1 RoHS compliant?
Yes, it is ROHS3 compliant.
What is the pitch of 1-794066-1?
The mating pitch is 0.163" (4.14 mm) with the same row spacing.
