TE Connectivity AMP Connectors Micro MATE-N-LOK header, 14 circuits, 3.00 mm pitch, right-angle SMT, gold-plated mating contacts, shrouded 4-wall, locking ramp, UL94 V-0, -40°C~105°C
| Parameter | Value |
|---|---|
| Series | Micro MATE-N-LOK |
| Type | Male Pin |
| Mounting | Surface Mount, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 250V |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C~105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.290\" (7.37mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Features | Board Lock |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.118\" (3.00mm) |
| Positions | 14 |
| Row spacing - mating | 0.118\" (3.00mm) |
| Contact finish - post | Tin-Lead |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 1-794625-4: Board locks on the SMT feet anchor the header during reflow soldering and improve shear resistance from cable strain after assembly.
No stock-holding claim; sourced per request against the BOM quantity.
Voltage rating is 250 V.
The 1-794625-4 is obsolete from the manufacturer. We source it through independent distribution — submit an RFQ with your target quantity, and we confirm availability and current pricing at quote time. No stock-holding claim; each lot is verified per request.
The 1-794625-4 is a unique configuration in the Micro MATE-N-LOK series — a board spin may be required if a substitute is needed.
The 3.00 mm pitch, 14-position, 2-row layout is keyed by the shrouded 4-wall design — confirm the mating half part number against the series catalog before ordering.
