TE Connectivity AMP Connectors AMPMODU Mod II header, order code 1-825440-0, 20 positions, dual row, 0.100" (2.54 mm) pitch, gold mating contacts, through-hole, solder termination, unshrouded.
TE 1-825440-0 Header, 20-Pos, 0.100" Pitch, AMPMODU Mod II
MPN1-825440-0
Active
TE Connectivity AMP Connectors AMPMODU Mod II header, order code 1-825440-0, 20 positions, dual row, 0.100" (2.54 mm) pitch, gold mating contacts, through-hole, solder termination, unshrouded.
$1.5902Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Operating temperature | -65°C~105°C |
| Contact material | Brass |
| Insulation color | Green |
| Insulation height | 0.110\" (2.79mm) |
| Insulation material | Polybutylene Terephthalate (PBT) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
All specifications
| Parameter | Value |
|---|---|
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 20 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.126\" (3.20mm) |
| Overall contact length | 0.500\" (12.70mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.264\" (6.70mm) |
| Contact finish thickness - post | 98.4µin (2.50µm) |
| Contact finish thickness - mating | 3.90µin (0.099µm) |
Product details
Frequently asked questions
What is the closest pin-compatible alternative to 1-825440-0 in the AMPMODU Mod II family?
Within the same series, the 10-position 825440-1 and the 50-position 1-825440-5 share the same pitch, row spacing, and unshrouded design — only the position count differs.
What compliance documentation is available for 1-825440-0?
RoHS and REACH compliance documentation is available from TE Connectivity.
