TE Connectivity AMPMODU Mod II unshrouded header, 22 positions, 2 rows, 0.100" (2.54 mm) pitch, male pin, square contact, through-hole solder termination, gold mating finish, UL94 V-0, bulk packaging.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Green |
| Insulation height | 0.110\" (2.79mm) |
| Insulation material | Polybutylene Terephthalate (PBT) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 22 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.126\" (3.20mm) |
| Overall contact length | 0.500\" (12.70mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.264\" (6.70mm) |
| Contact finish thickness - post | 98.4µin (2.50µm) |
| Contact finish thickness - mating | 3.90µin (0.099µm) |
The 1-825440-1 is a 22-position, dual-row unshrouded header from TE Connectivity's AMPMODU Mod II series. The male pin contacts are square and gold-plated on the mating surface (3.90 µinch thickness), which provides reliable signal-level connections in repeated-mate applications.
The 1-825440-1 is available through independent distribution. It is quoted to order against your BOM quantity — no stock-holding claim is made.
All positions are loaded.
