Breakaway header, 14 circuits, single row
The 1-826629-4 is the 14-circuit member of TE's AMPMODU Mod II breakaway header line, unshrouded, push-pull fastening, suited for board-to-board or cable connections.
1-826629-4 TE AMPMODU Mod II Header, 14 Pos, 2.54mm
MPN1-826629-4
Active
TE Connectivity AMP Connectors AMPMODU Mod II header, breakaway, order code 1-826629-4, 14 positions, single row, 0.100" (2.54 mm) pitch, 5 A, gold-plated mating contacts, through-hole, solder termination.
$1.7337Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 5A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Green |
| Insulation height | 0.110\" (2.79mm) |
| Insulation material | Polybutylene Terephthalate (PBT) |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 14 |
| Contact finish - post | Tin |
| Contact length - post | 0.126\" (3.20mm) |
| Overall contact length | 0.500\" (12.70mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.264\" (6.70mm) |
| Contact finish thickness - post | 118.1µin (3.00µm) |
| Contact finish thickness - mating | 3.90µin (0.099µm) |
Product details
Frequently asked questions
What compliance documentation does TE Connectivity AMP Connectors provide for 1-826629-4?
The insulator material is Polybutylene Terephthalate (PBT) rated UL94 V-0.
