It is unshrouded, meaning the pins are exposed after soldering; the mating receptacle provides the housing alignment.
5 A Current Rating with Gold Mating Finish
The mating surface is gold-plated (3.90 µinch over nickel), while the solder posts are tin (118.1 µinch).
Active Production — Sourced per BOM Quantity
Lifecycle status is Active with RoHS compliance confirmed. The base product number is 826634; the full 1-826634-0 suffix denotes the specific plating, pin length, and packaging variant. Sourced against your BOM line quantity.
Mates with Standard 2.54 mm Receptacles
This header mates with any 20-position, dual-row, 2.54 mm pitch socket or receptacle — including AMPMODU Mod II female housings and IDC connectors. The contact mating length is 0.264 inches (6.70 mm), which provides a generous wipe zone inside the receptacle contact beam.
