TE Connectivity AMP Connectors 1-86479-3 — Pin Headers

1-86479-3 TE AMPMODU Mod II 2-Pin Right-Angle Header

MPN1-86479-3
Active

TE Connectivity AMP Connectors AMPMODU Mod II header, 1-86479-3, 2-position unshrouded male pin, through-hole right-angle, 0.100" (2.54 mm) pitch, 3 A, gold mating finish, RoHS.

$1.6500Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 1-86479-3 datasheet (PDF)
RoHSRoHS Compliant
SeriesAMPMODU Mod II
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

1-86479-3 key specifications
ParameterValue
SeriesAMPMODU Mod II
TypeMale Pin
MountingThrough Hole, Right Angle
Connector typeHeader
Fastening typePush-Pull
Current rating3A
Operating temperature-65°C~105°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.238\" (6.05mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0

All specifications

1-86479-3 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageTray
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Positions2
Row spacing - mating0.100\" (2.54mm)
Contact finish - postGold
Contact length - post0.110\" (2.79mm)
Contact finish - matingGold
Contact length - mating0.318\" (8.08mm)
Contact finish thickness - postFlash
Contact finish thickness - mating30.0µin (0.76µm)

Product details

The 1-86479-3: The insulation height of 0.238" (6.05 mm) gives the mating connector clearance above the board surface. Rated at 3 A per contact, this header suits signal-level interconnects in control, instrumentation, and low-power board stacks.

The part is RoHS Compliant per current TE compliance documentation.

This unshrouded header mates with AMPMODU Mod II receptacles and other 0.100" pitch female sockets. The push-pull fastening type means the connector is held by friction only — no latch or lock — so it is best suited for applications where the mated pair is not subject to vibration or accidental disconnection. Termination is solder through-hole. The square male pins (0.025" square typical for the series) accept wire-to-board or board-to-board mating.

Frequently asked questions

What is the current rating of 1-86479-3?

The 1-86479-3 is rated at 3 A per contact. This is a signal-level current rating suitable for control, instrumentation, and low-power board interconnects.

Does 1-86479-3 have a locking mechanism?

No. The 1-86479-3 uses a push-pull fastening type — it relies on friction from the pin-to-socket interference fit. There is no latch, detent, or secondary lock. For applications subject to vibration or cable strain, a shrouded header with a locking feature (such as the 1-1871673-2) would be more appropriate.
