TE Connectivity AMPMODU Mod II unshrouded header, 24 positions, dual row, 0.100" (2.54 mm) pitch, through-hole right-angle, male pin, gold-plated contacts, 3 A, UL94 V-0, tray.
1-87230-2 TE AMPMODU Mod II Header, 24 Pos, 0.100" Pitch
MPN1-87230-2
Active
TE Connectivity AMPMODU Mod II unshrouded header, 24 positions, dual row, 0.100" (2.54 mm) pitch, through-hole right-angle, male pin, gold-plated contacts, 3 A, UL94 V-0, tray.
$7.4500Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.238\" (6.05mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tray |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 24 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Gold |
| Contact length - post | 0.110\" (2.79mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - post | Flash |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
Where can I buy 1-87230-2 and what is the lead time?
1-87230-2 is an active part from TE Connectivity AMP Connectors. No stock-holding claim is made — each order is sourced independently.
What is the mating connector for 1-87230-2?
This unshrouded header mates with AMPMODU Mod II female socket housings or receptacles that accept 0.025" square pins on 0.100" centers.
