TE Connectivity AMPMODU Mod I receptacle, bottom entry, order code 1-87993-6, 16 positions, single row, 0.156" (3.96mm) pitch, tin-plated mating contacts, through-hole, solder termination.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod I |
| Type | Female Socket |
| Mounting | Through Hole |
| Connector type | Receptacle, Bottom Entry |
| Fastening type | Push-Pull |
| Operating temperature | -65°C~105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.300\" (7.62mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Parameter | Value |
|---|---|
| Package | Tube |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.156\" (3.96mm) |
| Positions | 16 |
| Contact finish - post | Tin |
| Contact length - post | 0.112\" (2.84mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 78.7µin (2.00µm) |
The 1-87993-6 is the 16-position member of TE's AMPMODU Mod I receptacle line, a single-row bottom-entry socket with push-pull fastening.
Through-hole mounting with a 0.112" (2.84mm) post length provides mechanical retention during soldering and service.
