TE Connectivity AMP Connectors 1-963211-1 — Pin Headers

1-963211-1 TE Connectivity Junior Power Timer Header, 6 Pos

MPN1-963211-1
Active

TE Connectivity AMP Connectors Junior Power Timer, 1-963211-1, 6-position plug header, 5.00 mm pitch, right-angle through-hole, shrouded 4-wall, lever lock, tin-plated contacts, black PBT housing, RoHS

$7.4200Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesJunior Power Timer
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

1-963211-1 key specifications
ParameterValue
SeriesJunior Power Timer
TypeTab
MountingThrough Hole, Right Angle
Connector typePlug
Fastening typeLever Lock
Contact materialCopper Alloy
Insulation colorBlack
Insulation height1.055\" (26.80mm)
Insulation materialPolybutylene Terephthalate (PBT), Glass Filled
StyleBoard to Board or Cable
PackageBulk
FeaturesMounting Flange

All specifications

1-963211-1 additional specifications
ParameterValue
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose
Contact shapeRectangular
Rows2
Pitch0.197\" (5.00mm)
Positions6
Row spacing - mating0.236\" (6.00mm)
Contact finish - postTin
Contact length - post0.122\" (3.10mm)
Contact finish - matingTin

Product details

Junior Power Timer header for automotive and general-purpose board-to-wire connections

Locking and termination that hold up in a running vehicle

A lever lock on the shroud secures the mating connector against vibration — the lever pulls the pair together and holds them until deliberately released. The 4-wall shrouded housing protects the tin-plated rectangular tabs from stubbing during blind mating, and the mounting flange adds a mechanical anchor to the board. Termination is solder to the through-hole posts (3.10 mm long), so the assembly holds up to reflow or hand-soldering without the contact loosening in the PBT housing.

Sourcing and compliance for production and replacement

RoHS compliant, bulk packaged, and supplied by TE Connectivity AMP Connectors.

Frequently asked questions

What is the pitch and position count of 1-963211-1?

5.00 mm mating pitch, 6 positions, all loaded, with a 6.00 mm row spacing.

Is 1-963211-1 RoHS compliant?

Yes, RoHS compliant per the manufacturer listing.

Can 1-963211-1 be replaced by 1-1871673-2?

No — 1-1871673-2 is a 4-position, 2.50 mm pitch header with a detent lock and square pins, not a functional equivalent to the 6-position, 5.00 mm pitch lever-lock header with rectangular tabs.
