TE Connectivity Junior Power Timer receptacle housing, 1-967240-1, 10 positions, 2 rows, 5.00mm pitch, 6.00mm row spacing, sealed, black PBT, free hanging, crimp termination, contacts not included.
| Parameter | Value |
|---|---|
| Series | Junior Power Timer |
| Type | Female Socket |
| Mounting | Free Hanging (In-Line) |
| Connector type | Receptacle |
| Operating temperature | -40°C ~ 85°C |
| Color | Black |
| Insulation material | Polybutylene Terephthalate (PBT), Glass Filled |
| Note | Contacts Not Included |
| Pitch | 0.197\" (5.00mm) |
| Package | Bulk |
| Features | Sealed |
| Row spacing | 0.236\" (6.00mm) |
| Rows | 2 |
| Contact termination | Crimp |
| Positions | 10 |
The housing is sealed, so it suits applications where moisture or dust ingress is a concern — think engine bay or underhood harnesses in automotive, or outdoor industrial controls.
The 1-967240-1 carries 10 circuits.
The sealed design means the housing includes a perimeter seal or individual cavity seals (depending on the variant) that compress when mated to the header, keeping the connection water- and dust-tight.
The 1-967240-1 housing accepts the standard Junior Power Timer female socket crimp terminals. The contacts are not included with this housing and must be ordered separately. Use the TE application tooling for the correct crimp profile.
Yes, the 1-967240-1 housing is listed with the feature 'Sealed', meaning it provides environmental sealing against moisture and dust when mated with the corresponding header. This makes it suitable for underhood and outdoor applications.
