TE Connectivity AMP Connectors AMPMODU Mod II, 102203-5, 8-position, 0.100" (2.54mm) pitch, shrouded right-angle header, through-hole solder, gold-plated mating contacts, 3A rated.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.214\" (5.44mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 8 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.110\" (2.79mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.240\" (6.10mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 102203-5: The shrouded 4-wall housing guides the mating connector and protects the pins during handling.
No stock-holding claim – availability checked per inquiry.
Mates with any AMPMODU Mod II or compatible 0.100" pitch IDC receptacle or socket housing designed for shrouded headers.
Submit your BOM quantity for current pricing and lead time confirmation. No stock-holding claim – availability is checked per inquiry.
No. The post finish is tin-lead, so it is RoHS non-compliant. Suitable for legacy builds with a RoHS exemption.
0.100" (2.54mm) pitch, single row, 8 positions.
Any AMPMODU Mod II or compatible 0.100" pitch IDC receptacle or socket housing designed for shrouded headers. The push-pull fastening means no latch – the shroud provides retention.
