TE Connectivity AMP-Latch 103309-2, Board to Cable/Wire header, 14 circuits, 0.100" (2.54mm) pitch, shrouded 4-wall, through-hole solder termination, male square pins.
| Parameter | Value |
|---|---|
| Series | AMP-Latch |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 1A per Contact |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.388\" (9.86mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Parameter | Value |
|---|---|
| Package | Tube |
| Features | Keying Slot |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 14 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Gold or Gold-Palladium |
| Contact length - mating | 0.240\" (6.10mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 103309-2: It mates with AMP-Latch socket connectors for board-to-cable/wire applications. The shrouded 4-wall design protects the pins during mating and provides keying slot alignment, reducing mis-mate risk in production.
Pricing and availability are confirmed at quote time against your BOM quantity. No single-vendor lock — the AMP-Latch family crosses to multiple manufacturers for the socket half.
The mating pitch is 0.100" (2.54mm), with the same row spacing.
It is a male pin header with square pins.
