TE Connectivity AMPMODU Mod II, 0.100" (2.54mm) pitch, 9 positions, 3 rows, unshrouded header, through-hole solder termination, 3 A per contact, gold mating finish, black thermoplastic housing, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.120\" (3.05mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Box |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 3 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 9 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.470\" (11.94mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
In a production harness that mates and unmated 50 times over the product life, this plating grade keeps the contact interface stable without tin-whisker or fretting concerns. The solder tails carry a tin-lead finish (100 µinch), which wets well during wave solder and gives a reliable fillet on the PCB pad.
It is quoted to order against your BOM quantity — submit an RFQ for current pricing and availability.
0.100" (2.54mm) pitch, 3 rows, 9 positions total, all positions loaded.
