TE Connectivity AMPMODU MTE series, 103904-7, 8-position single-row shrouded header, 0.100" (2.54mm) pitch, through-hole right-angle termination, gold-plated mating contacts, rated 3A, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | AMPMODU MTE |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Current rating | 3A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Features | Board Lock, Keying Slot |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 8 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.130\" (3.30mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Termination is solder — the 0.130" (3.30mm) post length fits standard through-hole PCB thicknesses.
RoHS compliance is not explicitly confirmed in the available records — confirm with the supplier at RFQ if RoHS is a BOM requirement.
The mating connector is an AMPMODU MTE 8-position receptacle housing that accepts the matching crimp socket terminals. The 0.100" pitch and single-row layout must match, and the receptacle must have the latch feature to engage the header's latch holder.
