TE Connectivity AMP Connectors 104074-1 — Pin Headers, Sockets & Housings

104074-1 TE Connectivity AMPMODU System 50 Header, 10-Pos

MPN104074-1
Active

TE Connectivity AMPMODU System 50 header, 104074-1, 10 positions, 1.27mm pitch, single-row, right-angle through-hole, shrouded 2-wall, gold mating contacts, latch holder, UL94 V-0, -65°C to 105°C.

$3.1264Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 104074-1 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

104074-1 key specifications
ParameterValue
SeriesAMPMODU System 50
TypeMale Pin
MountingThrough Hole, Right Angle
Connector typeHeader
Fastening typeLatch Holder
Voltage rating30VAC
Operating temperature-65°C ~ 105°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.190\" (4.83mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0

All specifications

104074-1 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageBulk
FeaturesBoard Guide
ShroudingShrouded - 2 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose, Medical, Telecommunications
Contact shapeCircular
Rows1
Pitch0.050\" (1.27mm)
Positions10
Contact finish - postTin-Lead
Contact length - post0.100\" (2.54mm)
Contact finish - matingGold
Contact length - mating0.125\" (3.18mm)
Contact finish thickness - post150.0µin (3.81µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

10-Position, 1.27mm Pitch Right-Angle Header

The 104074-1 is a 10-position, single-row header from TE's AMPMODU System 50 series, on 0.050-inch (1.27mm) pitch. Mating contacts are gold-plated at 30.0 µinch (0.76µm) over copper alloy — this thickness supports repeated mating cycles typical in field-service or test applications without fretting corrosion.

This header mates with AMPMODU System 50 receptacles — the 2-wall shroud and latch holder ensure a secure, polarized connection. The contact finish on the post is Tin-Lead at 150.0 µinch (3.81µm) — solderable with standard tin-lead processes.

Frequently asked questions

What is the mating connector for 104074-1?

The 104074-1 mates with AMPMODU System 50 receptacles — look for a 10-position, 1.27mm pitch receptacle with a latch-compatible housing. The 2-wall shroud and latch holder ensure a polarized, vibration-resistant mate.

Is 104074-1 RoHS compliant?

The contact finish on the post is Tin-Lead, which typically exempts it from RoHS compliance under certain categories. Confirm the specific RoHS status with the supplier at quote time, as the evidence does not list an explicit RoHS certification.
