TE Connectivity AMPMODU System 50 header, 15 positions, 0.050" (1.27mm) pitch, shrouded 2-wall, through-hole right-angle, gold mating contacts, UL94 V-0 thermoplastic housing, active production.
| Parameter | Value |
|---|---|
| Series | AMPMODU System 50 |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 30VAC |
| Operating temperature | -65°C~105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.190\" (4.83mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Features | Board Guide |
| Shrouding | Shrouded - 2 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Circular |
| Rows | 1 |
| Pitch | 0.050\" (1.27mm) |
| Positions | 15 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.100\" (2.54mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.125\" (3.18mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 104074-3: This is a 15-position, single-row header from the AMPMODU System 50 series, with a 0.050" (1.27mm) pitch that sets the board footprint and per-contact current ceiling.
The through-hole solder tails (0.100" post length) provide mechanical retention during assembly and rework.
The tin-lead post finish (150 µinch) is compatible with standard soldering processes.
The 104074-3 has a 0.050" (1.27mm) pitch, single row, with 15 positions fully loaded.
