TE Connectivity AMPMODU MTE header, order code 104361-8, 9 positions, single row, 2.54 mm pitch, 3 A, gold-plated mating contacts, through-hole right-angle, solder termination.
| Parameter | Value |
|---|---|
| Series | AMPMODU MTE |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Current rating | 3A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Features | Board Lock, Keying Slot |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 9 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.145\" (3.68mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 104361-8 is the 9-circuit member of TE's AMPMODU MTE header line, a single-row shrouded header with 2.54 mm pitch for board-to-board or cable connections.
The latch holder fastening and keying slot prevent the mating receptacle from backing out under vibration—useful in automotive or industrial enclosures where the harness gets tugged.
No pin-compatible alternative is recorded in the AMPMODU MTE series for this exact 9-position, single-row, 2.54 mm pitch, shrouded header with board lock and keying slot. The base product number 104361 covers the series; confirm the mating half and position count before ordering.
