Board-to-board receptacle, 50 positions, 1.27 mm pitch
The 104550-6 is the 50-position dual-row member of the TE Connectivity AMPMODU System 50 receptacle line, a board-to-board connector with a 1.27 mm mating pitch. Gold-plated mating contacts rated 30 VAC, surface-mount solder termination, and an integral board lock for reflow retention.
Stack height and row spacing
The row spacing is 2.54 mm, and the mated stack heights are 11.94 mm or 13.08 mm, accommodating two board-to-board z-height budgets from the same footprint.
